Etikettskrivare/Kvittoskrivare Eltron TLP2242 Eltron TLP2242 Thermal Transfer Printer

– List Price $895 SEK = 6300,00 + moms

Eltron's printers 2242 Series, incorporates a new design providing easy access to the print head and making loading ribbons and labels a snap!

These printers come standard with a 4 inch print width, 203 dpi print resolution and up to 512KB memory in a removable cartridge.

The 2242 Series supports many bar code symbologies including 2-D codes (PDF-417 & MaxiCode).

The small footprint and small price tag sets new price performance standards in thermal transfer printing.

Maximum print width- 4.09" (104 mm) Minimum media width- 1.12" (28mm) Maximum media length – 5.75" (146mm) Minimum media length- .38" (9.7mm) or 5" (12.7 mm) when using the label present sensor Fonts

– International character sets standard

– Five alpha numeric fonts from .049" (1.25mm) to .23" (6.0mm) high

– All fonts are expandable vertically and horizontally up to 8x – Fonts can be printed in four directions: 0, 90, 180, and 270

– Smooth scalable fonts can be downloaded from CREATE A LABEL Bar code Specifications

– Standard (One Dimensional) Bar Codes – Code 39 – Extended Code 39 – Code 93 – Extended Code 93 – Code 128 UCC – Code 128 Subsets A, B, and C – Codabar – Interleaved 2 of 5 – UPC-A, UPC-E, 2 & 5 digit add-on – UPC Shiping container code – EAN-8, EAN-13, 2 & 5 digit add-on – EAN-128 – POSTNET Two Dimensional Bar Codes – Maxicode – PDF-417

Printing Specifications

– Thermal transfer and direct thermal printing

– Selectable constant print speeds of 1" (25mm), 1.5" (38mm) or 2" (51mm) per second

– 203 dots per inch (8 dots/ mm) print resolution

– Maximum print width 4.09" (104mm)

– Bar codes printed with or without human readable text Ribbon Specifications

– Types: wax, wax/resin, resin

– Standard widths 1.3" (33mm), 2.5" (64mm), 3.3" (84mm), 4.3" (109mm)

– Length: lengths for a 1:2 ratio of label vs. ribbons, 3.360" (85.34m) max

– Ribbon Roll Capacity: 1.39" (35.3mm) max O.D. on a .5 (12.5mm) I.D. core. Ribbon length approx. 3600" (91m)

– Other widths available on a customer order basis

Communications Interface – Centronics Parallel – RS-232C (DB-9)

– Serial with software selectable rates of 1,200 to 19,200 baud – XON/ XOFF, CTS/DTR handshaking

– Programmable 7 or 8 data length, 1 or 2 stop bits selectable parity Mechanical

– Size:7.9" (200mm) W x 8.9" (226mm) D x 5.32" (135mm) H

– Printer Weight: 4 lbs. (1.81 Kg)

Electrical – Power 110/220 VAC +/- 10% – Single phase 60/50 Hz at 1 Amp.Max.

– Compiles with FCC Class A and CE standards – UL and TUV-GS agency approved Environmental

– Operating temp 40-104 degrees F (5-40 degrees C) – Storage Temp 40-140degrees F (-40 to 60 degrees C)

– Humidity: 10%- 90% non condensing, Ventilation: free air

Levereras med kraftaggregat

Vikt 3,5 Kg Paket
